Rear Park Distance Control Assist

Rear Park Distance Controls

Description

Features:

  • Reverse gear activation
  • Adjustable volume warning beeper
  • Programmable Zone -Up to 1.6metre range
  • 4 sensors
  • 1 year guarantee
  • Colour coding optional – Sensors come in black

Changeable detection range and Pa height where sensors need to be fitted low or detection occurs too early, making the PRO a solution for most vehicles.

Self-learning sensitivity program function – after installation the ECU can be programmed automatically to detect the height and positioning for better detection results with minimal false alarms. The ECU remembers the settings with no need for additional programming.

Intuitive intelligence – the sensors learn each time they are activated if there are any stationary objects in the detection zone. Tow bars can be added or taken away without the need for interference with the ECU. Dynamic detection is also a key feature, and this enables the sensors to ignore objects that are moving away from the vehicle.

Advanced triangulation – the detecting zone of the sensors is squared off to ignore the far sides of the rear of the vehicle, and this helps when parking in garages and alongside walls, traditional sensors do not account for this.

The kit includes flush fitting sensors and angle rings as standard for curved and low bumpers and black silicone seals. The angle rings range in inclination being 3, 6 and 12 degrees. Advanced self-diagnosis will be audibly sound to advise if there is a fault with the product and provide details of any faulty sensor.

Specifications
Rated Voltage: 12 (DC V)
Operating Voltage: (9 ~ 16 DC V)
Operating Current: 150mA max.
Operating Temperature: -30 ~ 85
Storage Temperature: -40 ~ 85
Ambient Humidity: 90 RH max.
Protection Grade Sensor: IP67 / ECU: IP40
